Compatible DWDM XFP C band YXFiber FTLX3812M337 SFP 10G 80KM
XFP-10G Compatible XFP 1550nm 80km DOM Transceiver Module
Product Features
1. Supports 9.95 to 11.3Gb/s bit rates
2. Simplex LC Connector
3. Hot-pluggable XFP footprint
4. Uncooled 1270nm DFB transmitter, 1330nm PIN photo-detector
5. Uncooled 1330nm DFB transmitter, 1270nm PIN photo-detector
6. Applicable for 10km SMF connection
7. Low power consumption, < 1.8W
8. Digital Diagnostic Monitor Interface
9. XFP MSA package
10. Operating case temperature: Commerical:0 to 70 °C Industrial:-40 to 85 °C
Applications
1.10GBASE-LR at 10.3125Gbps
2.10GBASE-LW at 9.953Gbps
3. Other optical link
Product Descriptions
YXFiber 10G-XFP-LR Simplex is compliant with the IEEE803.3ae 10Gbase-Bx. and transmission distance up to 10km on SMF .The transceiver module comprises a transmitter with a 1270 or 1330nm DFB laser transmitter, an integrated 1330 or 1270nm detector preamplifier(IDP) mounted in an optical header and a limiting post-amplifier IC. Transmitter and receiver are separate within a wide temperature range of 0℃ to +70℃ for commercial temperature, -40 to 85 °C for industrial temperature, and offers optimum heat dissipation and excellent electromagnetic shielding for 10 GbE systems application.
FAQ
1. Do you provide samples? Is it free or extra?
Yes, but we need to charge for samples, we will return sample fee in the later order
2. What is your MOQ and the lead time?
We do not have MOQ, 1sample is available
3. What is your terms of payment?
Pament≤5000USD, 100% in advance
Payment> 5000USD, 40%T/T in advance, balance before shipment
4. How about Precautions?
Storage in anti-static box
When used, please ensure that the voltage is normal and stable
5. What is your after-sales service?
All our customers can enjoy the after-sales service for the three years quality warranty, and
lifetime technical support
6. Could I use our own logo and label?
Yes, we could provide OEM service and make the products with your own label
