Gigabit Ethernet DW-SFP40-10G 80km CH23 ER 10G DWDM SFP+

Product Categories

Wuhan Yongxinfeng Science & Technology Co., Ltd.

Contact Now

Gigabit Ethernet DW-SFP40-10G 80km CH23 ER 10G DWDM SFP+

Name: Gigabit Ethernet DWSFP4010G 80km CH23 ER 10G DWDM SFP
Brand: YXFiber
Price: 150.00 USD

China Gigabit Ethernet DW-SFP40-10G 80km CH23 ER 10G DWDM SFP+ wholesale

Brand Name : YXFiber

Model Number : YXF-PP-DXXL-80D CH23

Certification : CE RoHS FCC

Place of Origin : Hubei, China

MOQ : 1pcs

Price : $150.00 / Piece

Payment Terms : T/T, L/C, Western Union

Supply Ability : 100000pcs per month

Delivery Time : 1~3working days after payment

Packaging Details : 10pcs in Plastic tray

Type : Optical Fibers

No. of Fiber : 2.

Use : FTTH

Supply Voltage : 3.3V

Power : 0~+4dBm

Data rate : 10Gbps

Wavelength : 1559.79nm

Transmission distance : 80km

Interface : Duplex LC

Power consumption : <2W

Standard : 0°C to +70°C

Laser Type : EML DWDM

Sensitivity : <-23dBm

Application : (Data Center)

Port : Wuhan

Contact Now

10G DWDM CH23 1559.79nm 80km SFP+ Module Duplex LC

Channel can choose from CH17-- CH60

Features:

DWDM PON network

ITU-T DWDM grid wavelengths

Data rate selectable ≤4.25Gbps or 9.95Gbps to 11.3Gbps bit rates

Temperature Stabilized DWDM DFB Transmitterd

Multi channels optional

Low Power Dissipation 1.5W Maximum

Excellent ESD protection

-5ºC to 70ºC Operating Case Temperature

Single 3.3V power supply

Diagnostic Performance Monitoring of module temperature,

Supply Voltages, laser bias current, transmit optical power,

receive optical power

RoHS compliant and lead free

Application

Gigabit Ethernet

ATM

DWDM System

Fiber links

Specification 10G DWDM SFP+

Product type	Data Rate	Wavelength	Reach	LD	TX Power	PD	Rx Sens
DWDM SFP+	10G	15xx.xx nm	40Km	EML	-1~3dbm	PIN	<-20dbm
DWDM SFP+	10G	15xx.xx nm	80Km	EML	0~4dbm	APD	<-24dbm
DWDM XFP	10G	15xx.xx nm	40Km	EML	-1~3dbm	PIN	<-16dbm
DWDM XFP	10G	15xx.xx nm	80Km	EML	0~4dbm	APD	<-24dbm

Gigabit Ethernet DW-SFP40-10G 80km CH23 ER 10G DWDM SFP+

ER 10G DWDM SFP+

80km DWDM SFP Transceiver

Gigabit Ethernet DW-SFP40-10G 80km CH23 ER 10G DWDM SFP+ Images
